Скачать или смотреть Instrument Cluster Display / Change Oil Message | How To | 2023 Ram 1500 DT

2023 Ram 1500 DT features an automatic oil change message to let you know when an oil change is required. This feature will help you know how often to change your oil and/or oil filter. Learn how to reset the oil change indicator after a scheduled oil change. This feature can greatly prolong your oil life.

Transcript

[music playing]

[voice over] Your Instrument Cluster Display, or ICD, is a driver-interactive feature located in the instrument panel. It monitors vehicle systems and lets you know if there’s an issue. The steering wheel-mounted controls let you scroll through the main menus and sub-menus to access specific information. Just use the up and down arrow buttons to scroll. Push and release the right arrow button to select. To reset the displayed information, push and hold the OK button for 2 seconds. To return to the main menu from an info screen or sub-menu item, push the left arrow button.
You can learn more about vehicle information, fuel economy, off-road systems, trip functions, and more.

To customize your Instrument Cluster Display, just push and release the up or down arrow button until the Screen Setup menu item is highlighted in the ICD. Push and release the right arrow button to enter setup. From here, you can select different areas of the ICD you want to customize. For example, you can display a compass in the upper left, outside temperature in the upper right, and average miles per gallon in the center. Some ICDs may have additional locations to display even more info, so you can set it up to match your needs.

[text on screen] Next Up… Change Oil Message

[voice over] Your oil change indicator system can help take the guesswork out of oil changes.
When it’s time to change the oil, you’ll hear a chime and the Oil Change Required message will appear briefly in the instrument cluster. The system is duty-cycle based, so the oil change interval may fluctuate according to your driving style. Keep in mind, though. Until reset, the oil change message will continue to appear every time you turn on the ignition.

To reset the oil change indicator system after a scheduled oil change, put the vehicle in Park. With your foot off the brake, push the Engine Start/Stop button twice to put the ignition into the On/Run position. Don’t actually start the engine, though.

Now, use the steering wheel arrow controls to find the Oil Life submenu in the Vehicle Info section of your instrument cluster display. Then, just push and hold the OK button until the gauge resets to 100%.
If you still see the message when you start the vehicle, the system did not reset, and you’ll need to repeat this procedure.

This video is not intended to take the place of your Owner's Manual. For complete details and other important safety information, please see your Owner's Information.
