Dgen Teleios Grande H12 – Super wide 3.3m high speed direct to textile printer.
Built-in heat fixation unit – small & compact, convenient, instant, efficient.
6 colour, for both disperse dye ink and textile pigment ink.
12 Ricoh Gen5 printhead technology – industrial 600dpi native resolution.
Maximum speed is 228m2/hr at 600dpi, while 1,200dpi can be achieved at speeds of 143m2/hr and 1,800dpi at 98m2/hr.

The Grande H12 is targeted at the soft signage market for applications including flags, trade show displays, lightboxes, table covers, banners and tents. It can also be used for home textiles



SPECIFICATIONS:

Print head: native 600 dpi, 7 pl/ dot. 8 level grey scale
Number of nozzles: 2560 nozzles
Colors: x 6 colours
Printing Width: 300~3200mm
Margin: 10mm on both sides (10mm of media guide is used)
Media Thickness: 1.5mm max
Roll diameter Feeder and Take-up rolls: 280mm MAX.(11 inch)
Core diameter: 76.2mm (3 inches.)
Roll weight: 150 Kg MAX
Interface: 1000BASE-TX
Water-base inks:
C, M, Y, K, Lc, Lm, Orange, Turquoise, Penetration fluid
C, M, Y, K, Lc, Lm, Or, Blue
RIP Software: Wasatch, Onyx, Ergo Poster Print, Caldera
Printer power: AC380V 3Ø + N + PE, 20A (50/60 Hz), 11.4kW
Fixation unit: AC 380V 3Ø + N + PE, 25A (50/60 Hz), 16.5kW
Dimensions:
Printer 5014mm (W) x 1150mm (D) x 1665mm (H)
Total 5014mm (W) x 3030mm (D) x 1665mm (H)
