Скачать или смотреть Telecontrol Server Basic Setup

Hướng dẫn cài đặt phần mềm Telecontrol Server basic.
Download at:
https://drive.google.com/open?id=16Ny...
Description:
TeleControl Basic is a simple remote control and remote maintenance system optimized for the use of public communication networks such as mobile wireless and internet for connection to the substations.
It comprises the TeleControl Server Basic control center software and substations of the type SIMATIC S7-1200, ET 200SP and RTU3000C. In addition to communication between the control center and the substations, the system also enables internode communication between substations.
Small-scale applications with few outstations can be implemented, as well as large-scale plants comprising up to 5000 outstations.
TeleControl Server Basic

Software package for the PC, comprising:
OPC (UA) server, connection manager and configuration software for telecontrol and teleservice tasks for the following station types: SIMATIC S7-1200/S7-200, ET200SP and RTU family SIMATIC RTU3000C
PLC block library for the S7-200
Operation in wireless network or via Ethernet
SIMATIC S7-1200 with CP 1243-7 LTE and CP 1242-7 GPRS via dynamic IP addresses with a standard mobile phone flat-rate contract in the wireless network
SIMATIC S7-1200 with CP 1243-7 LTE and CP 1242-7 GPRS via fixed IP addresses in the wireless network
SIMATIC S7-1200 with CP 1243-1 via connection to Ethernet and by means of external DSL routers, e.g. SCALANCE M812-1
SIMATIC ET 200SP with CP 1542SP-1 IRC via connection to Ethernet and by means of external DSL routers, e.g. SCALANCE M812-1
SIMATIC RTU3010C autonomous telecontrol station via connection to Ethernet and by means of external routers, e.g. SCALANCE M812-1
The autonomous SIMATIC RTU3030C and RTU3031C telecontrol stations in the UMTS/3G mobile network
SIMATIC S7-200 with MODEM MD720 via dynamic IP addresses with a standard mobile phone flat-rate contract in the 2G wireless network (GPRS mode)
Connection of up to 5 000 telecontrol stations to the control center via the OPC (UA) interface
Operation and diagnostics of the telecontrol stations on an OPC (UA) server with different STEP 7 projects and separate users with user administration
Integral teleservice gateway for diagnostics of S7-1200/ET200SP stations with STEP 7 via the Internet, also with dynamic IP addresses. This works on every PC with STEP 7 and standard internet access without parameterizing firewalls or routers
Communication between SIMATIC telecontrol stations by means of routing function (also when using dynamic IP addresses)
Encrypted data transmission between TeleControl Server Basic and the telecontrol station for protection against data manipulation and tapping. For additional protection via VPN, the TeleControl Basic system can be combined with SINEMA Remote Connect.
Import of SINAUT MICRO SC projects
