Скачать или смотреть NextGEN DRSSTC UD3: Unboxing, Soldering, Startup and Software (Part 1 of 3)

This is the first video in a series of 3, on how to get started with the UD3 Tesla coil driver. Huge shoutout to Steve Ward, Netzpfuscher (Jens Kerrinnes), Malte0811 and TMaxElectronics (Thorben Zethoff) for their work on the UD3 platform.

HVF Thread on the development: https://highvoltageforum.net/index.ph...

The UD3 is a Tesla coil driver board for controlling a DRSSTC or QCW. The interrupter is embedded in the UD3 (Classic Mode / MIDI / SID(C64) / QCW Ramp). The UD3 was originally developed by Steve Ward.
Embedded interrupter with MIDI and SID audio modulation
Primary resonator fres measurement (frequency sweep)
Primary peak current measurement over feedback CT
Pulse skipping
Alarm/Event system for fault tracing
System fault interlocks for undervoltage/temperature/watchdog
Bus current measurement (current or voltage mode CT)
Controls up to 4 relays to handle inrush current and other things
Can control an external light display for showing selected parameters
It runs FreeRTOS, making it easy to add new functionality
Commandline over serial interface
Multi user commandline over MIN-Protocol
Dual voltage measurement (differential)
Support for Teslaterm and UD3-node
Telemetry over serial
Bootloader with serial/usb support (firmware update with Teslaterm)

UD3 github: https://github.com/Netzpfuscher/UD3/wiki
TeslaTerm github: https://github.com/malte0811/Teslaterm
FiberNet github: https://github.com/TMaxElectronics/UD...
UD3.1b github: https://github.com/TMaxElectronics/UD3.1
