Скачать или смотреть WHS-G3-401 3-point mechanical wafer gripper

The WHS-G3 is a precision-engineered, normally-closed three-point mechanical wafer pick designed for specialized wafer handling applications. It securely grips round substrates of 4" (100 mm) sizes, focusing on tangential edge handling. The WHS-G3 is an ideal tool for both laboratory single-wafer processing and wafer rescue operations, offering versatile performance across various environments.

Built with high-performance PTFE Teflon® grippers, the WHS-G3 withstands harsh chemicals and temperatures up to 250°C for short-term exposure. This durability makes it suitable for cleanroom use and chemical processes that require submersion of the wafer in liquids. The grippers, with a 50 mm height, allow for safe wafer handling while ensuring full immersion in chemical baths.

The tool features an adjustable stop mechanism on the trigger, allowing operators to modify spring tension for handling thin and compound wafers with care. Its ergonomic design ensures secure handling and ease of use during delicate operations, such as lifting wafers from flat surfaces or rescuing them from process tools and equipment like CMP polishers.

Manufactured in an ISO9001 certified environment and CE certified, the WHS-G3 meets stringent international standards for quality and safety. Its robust construction, paired with precision handling capabilities, makes it an indispensable tool for semiconductor labs and cleanroom environments requiring careful, reliable wafer manipulation.

An optional tabletop pedestal holder is available to keep the tool organized and clean between uses.

For more information please visit our website: https://www.sps-international.com/pro...
