This project involved a coordinated two-crane operation to set concrete bridge beams. Each beam weighed 52,000 pounds and required precise communication and controlled movement throughout the work.



The Liebherr LTM 1650 placed 6 beams independently, followed by 8 beams set using both cranes together, and the Grove GMK6300L then placed 6 beams independently to complete the span.



Liebherr LTM 1650 lift data

Beam weight: 52,000 lbs

Load per crane during dual picks: approximately 26,000 lbs

Radius: 120 ft

Counterweight: 165,300 lbs



Grove GMK6300L lift data

Beam weight: 52,000 lbs

Load per crane during dual picks: approximately 26,000 lbs

Radius: 112 ft

Counterweight: 164,000 lbs



Careful planning and coordination between both cranes allowed the beams to be placed safely and efficiently from start to finish.
