VOXTER UV-B5 (DUAL BAND)

Features:

Upto 99 Channel
Emergency Call/Alarm function
Commercial FM Radio
Dual Display/ Dualband/ Dual Standby
DTMF encoding
Incorporates 104 codes DCS and 50 privacy codes CTCSS programmable
CTCSS and DCS setting in different MENUs
Transmitter transmission (TOT)
Frequency step (5/6.25/10/12.5/20/25kHz)
Battery saving function
VOX (Voice operated transmission)
BCL (Busy channel lockout)
Low battery warning
Channel mode display (Name, Frequency, Channel)
DTMF tone of transmitting code
Scan resume method (TO/CO/SE)
PTT-ID (Press or release the PTT to transmit code; Press and release the PTT to transmit code)
Reverse function
PC Programming

Spesifications:
General
Frequency range
65MHz-108MHz (Only commercial FM radio reception)
VHF: 136MHz-174MHz (Rx/Tx)
UHF: 400MHz-470MHz (Rx/Tx)
Memory ChannelsUp to 99 channel
Frequency stability 2.5ppm
Frequency step 5kHz/6.25kHz/12.5kHz/20kHz/25kHz
Antenna impedance 50
Operating temperature -20C to +60C
Supply voltage Rechargeable Lithium-Ion 7.4V/2000 mAh
Mode of operation Simplex or semi-duplex
Duty cycle 03/03/54 min. (Rx/Tx/Standby)

Transmitter

RF power 5W/1W
Type of modulation F3E
Maximum deviation +5 kHz/+2.5 kHz (W/N)
Spuirious emissions 7.5uW
Ajacent channel power-65dB/-60dB

Receiver

Receiver sensitivity 0,2 V(at 12 dB SINAD)
Intermodulation 65dB
Audio output 1 W
Ajacent channel selectivity 65dB
Spuirious response 65dB
Receiving current 380mA
