Furibee FX120 Maiden flight car park test flight

Check out the item here https://goo.gl/QzF8dp

Addicted to mini quads and micro quads!
This 120mm X quad is definitely a good choice to add on to the collection of mini and micro quads!

I would really think this is a good platform to learn as it is small and convenient to bring it everywhere and practice whenever I have some minutes to spare. :)

Small enough to fly it anywhere!

Thanks for watching!

Who are we?
We are a group of passionate RC enthusiasts coming together weekly for RC fun. :)

Add us on Facebook
  / sgcrawlers
  / boolean21

Instagram
  / sgcrawlers

Visit us at http://SGCrawlers.co.nr and http://MyHoncho.blogspot.com

Subscribe to our youtube Channels
   / myhonchosg
   / booleanrc

Keep RC-ing!!! :D


Description
—————————————
Specifications:
Carbon Fiber Frame
Wheelbase: 120mm
Size: 140 x 140mm
Thickness: 2mm

F3 Flight Controller
The latest F3 flight controller with CleanFlight 1.12.0
All the functions are accessible
3-in-1 tower structure with integrated 4-in-1 ESC, FPV transmitter, and OSD

4-in-1 BLHeli 20A ESC
Integrated with PDB, BEC and battery power detection module
Supports 2 - 6S, Oneshot125 and BLHeli Suite settings
Firmware version: BLHeli 14.6

AIO FPV Camera
Resolution: 700TVL
Angle of lens: 148 degree FOV, 160 degree DFOV
Input voltage: 3.6 - 5.5V
TV system: PAL / NTSC switchable
Lens diameter: 15.3 x 14mm
Weight: 9.2g

1306 3100KV Motor
Input voltage: 2 - 3S
Continuous current: 7.6V
Shaft diameter: 5mm
Size: 34 x 17mm ( diameter x height )
Weight: 13g / piece

3045 Three-blade Propeller
Material: ABS + PC
Big windward area and reinforced hub
Specification
General
Type: Frame Kit
Racing Quadcopter Parameters
Wheelbase: 120mm
Motor
Model: 1306
KV: 3100
Shaft Diameter: 5mm
Motor Dimensions: 34 x 17mm ( diameter x height )
Max. Continuous Current (A): 7.6A
No. of Cells: 2 - 3S
CW / CCW: CCW,CW
Camera
Video Resolution: 520TVL (horizontal resolution)
Video Standards: NTSC,PAL
Sensor: CMOS
Rotatable: Yes
Lens Diameter: 14mm
Electronic Speed Controller
Firmware: BLHeli
Functions: Oneshot125
Continuous Current : 20A
Battery
Battery (mAh): 620mAh
Dimension and Weight
Product weight: 0.142 kg
Package weight: 0.550 kg
Product size (L x W x H): 14.00 x 14.00 x 7.00 cm / 5.51 x 5.51 x 2.76 inches
Package size (L x W x H): 22.00 x 11.00 x 27.00 cm / 8.66 x 4.33 x 10.63 inches
Package Contents
Package Contents: 1 x Drone, 1 x B3 Balance Charger, 1 x 7.4V 620mAh 30C LiPo Battery, 4 x Spare Propeller, 1 x Propeller Puller
