Скачать или смотреть 50km Vehicle Detection Long Range Thermal Night Vision PTZ Camera Gyro stabilized MIL-810-STD

Long Distance IR Infrared Night Vision 70~1400mm MIWR Cooled Thermal multi-sensor PTZ camera boasting a our long-range 135X 2075mm visible day/night camera, long-range 1400mm thermal infrared zoom, and optional ZLID NIR illumination with LRF. This multi-sensor payload enables the Vega to provide excellent imaging in virtually any environment from smoke and fog.


Cooled InSb Thermal Imager
The Vega contains a high sensitivity 15μm cooled InSb sensor
with a resolution of 640×480 and an ultra-long cooler lifetime of
20,000 hours MTBF. The cooled sensor is able to detect differences
in temperature as small as ±0.02°C. This provides more detail for
tracking of targets at extreme ranges in total darkness and through
most obscurants. 20X Continuous Zoom Germanium Lens
The cooled InSb thermal core is paired with a precision-engineered
ƒ/5.5 germanium zoom lens allowing you to view targets with a 20X
optical zoom range from 70mm to 1400mm. This allows for excellent detection of thermal targets by offering anything from a 7.8° to 0.39° horizontal field of view. These lenses also feature auto focus capabilities, delivering crisp, clear images even when adjusting zoom. This ensures optimal performance and situational awareness in the wide field of view and crisp details in the narrow field of view.

Visible/NIR Optical HD Camera
The Vega's visible camera was designed and optimized for long
range surveillance. It uses a 1/1.8" progressive scan CMOS sensor
with an HD resolution of 1920×1080 and a fantastic signal to noise
ratio of 55dB. The 1/1.8" sensor has excellent spectral sensitivity for both visible and NIR wavelengths and features an automatic IR cut filter, making it a true day/night camera providing clear color images by day and high sensitivity black and white images at night. The 1/1.8" sensor provides excellent “Starlight” low light sensitivity to get the most out of the lower light levels that are an unavoidable reality with long-range lenses. The Viper also integrates the latest technology in real-time image processing such as BLC, HLC, WDR, EIS, 3D DNR, ABF, Defog/Haze etc. Each of these image enhancements can be automatic or user-defined and calibrated based on the application requirements.



Long Range 135X Zoom Lens
The Vega comes equipped with a precision engineered 15.5–2075mm IR-corrected zoom lens with motorized HD doubler, offering an incredible 135X zoom range from 26° through to a very narrow 0.2° FOV when paired with the 1/1.8" sensor. That's equivalent to a “full-frame” DSLR camera using a 10,000mm lens. Infiniti’s zoom optics are built with the highest quality Japanese fluorite ELD low dispersion glass, and the integrated rapid auto focus allows long range recognition and identification of targets without operator intervention. The lens also incorporates a motorized fog filter that is used with the camera’s monochrome mode and de-haze image processing to see through fog, smoke, smog and haze that render standard optical cameras unusable. Infiniti’s HD Zoom camera is a perfect synergy between precision craftsmanship, state of the art sensor hardware and the latest image processing for unparalleled range and performance.

ZLID Laser Illumination
IR illumination allows for detailed video when there isn't enough
natural light, however for long-range IR illumination a laser is needed. Many laser illuminators overexpose the center of the screen and leave the edges dark. Infiniti’s ZLID (Zoom Laser IR Diode) technology synchronizes the IR intensity and area illumination with the zoom lens for outstanding active IR performance, eliminating over-exposure, washout, and hot-spots for clear images in complete darkness
