Скачать или смотреть Redlands EDX 700 Gold Purity Spectrum Analyser

Gold is a precious metal so it is very important to determine its purity in order to make sure that you have an authentic piece of gold. to check the karat level , it should be put under the analyzing process "Gold testing method".
Redlands offer you EDX 700 GOLD TESTING MACHINE,a versatile energy dispersive X-ray fluorescence spectrometer.It is economically priced, trade.Redlands
EDX 700 is an accurate, non-destructive means of testing the purity of gold.


Specification:

X-ray Source : X-ray Tube Ti or W cathode
HV Generator : 50kv adjustable in 200V steps Current adjustable in 1 A steps
Detector : Gas filled proportional counter
Detection Range : Au, Ag, Pt, Pd, Rh, Ru,Cu, Cd, Zn, Ni
Measurement Range : 1 - - - 99.99 %
Measurement Time : 30 - - - 300 seconds
Measurement Precision : ± 0.1% - In homogeneously melted sample ( Accuracy levels in comparison with fire assay result only )
Measurement Area : 20 mm
Working Temperature : 15 - - 25?C
Relative Humidity : 10 - - 80%
System Requirement : External PC with Windows XP or Windows 7(32bit)
Software : Windows Based
Power Requirement : 220V , 50Hz
Power Consumption :70W
Dimension : 410mm X 456mm X 492mm
Sample Chamber :255mm X 350mm X 98mm
Weight : 30 Kg

Application:

1: Retail Jewellery
2: Buying Old Gold
3: Quality Control
4: Gold Refinery
5: Gold Loan
