TruMark presents to you, Semi Automatic Tube Filling And Sealing Machine
Semi automatic tube filling and sealing machine is used for filling and sealing tubes like tooth paste , cosmetic creams, alovera gel, facewash, scrub, conditioner etc.
The filling machine can fill all type of low to high viscous products like liquids, gel, paste, cream etc

For this product please call or WhatsApp on +918080343943 between 11am to 5pmOr click below link to send WhatsApp message
http://api.whatsapp.com/send?phone=+9...
email : [email protected]
For our whole product range visit...
https://trumarkindia.blogspot.com/p/p...

You need to hold the tube below the nozzle and it will fill tube as per you filling range
(Your filling range would be in between of 100-1000ml) and then you can seal the tube by tube sealer. Both the machines are pneumatic and need air compressor
The Filling machine can withstand the particle of 100mm also
The sealing machine is suitable for both plastic and laminated tubes..

🔴~ FEATURES: TUBE FILLER

• All operations automatic except placing of Tubes
• foot switch can be provided for start stop operation
• All contact parts SS 304.
• Can fill thick paste as well as liquids with particles
• Easy change over from one size to another
• Fill accuracy up to ± 0.5% depending upon the material to be filled

🔴~ TECHNICAL DETAILS: TUBE SEALER
1. Adjustable sealing height
2. Fabrication Stainless Steel 304, Contact part SS304, Non contact Part MS with ENP Plating
3. Pneumatic operated: Need 1hp compressor or 6kg air minimum
4. Solenoid valve & FRL Janatics MAKE
5. Digital temperature controller
6. Electronic sealing timer for easy operation
7. This machine will have two Stations
1) Sealing 2) Trimming & Coding
8. Tube Trimmer for finished edge
9. Suitable for plastic as well as laminated tubes , Sealing quality is compatible with automatic machine
10. Quick changeover from one tube size to another(i.e. 25gm to 200gm)
11. Attendant: 1 operator , Output : 10-15 Tubes/min.
12. Power Consumption : 400 W


🔴~ PLEASE NOTE: FOR CLIENTS END
Need 2-3 HP air compressor, 3-4 CFM, with 60-80ltr tank size or higher, with a pressure switch to make compressor on or off & a FRL with humidity filter & dust filter
