An 𝐞𝐦𝐛𝐞𝐝𝐝𝐞𝐝 𝐦𝐢𝐜𝐫𝐨𝐟𝐥𝐮𝐢𝐝𝐢𝐜 𝐦𝐢𝐱𝐞𝐫 is a tiny device built directly into a microchannel to mix fluids, providing fast and uniform mixing in microscale volumes. For researchers working with laminar flow, that kind of built-in control can really simplify your experiments.

Recently, our team 3D printed an embedded microfluidic mixer* using 𝐂𝐲𝐭𝐨-𝐂𝐥𝐞𝐚𝐫 𝐏𝐡𝐨𝐭𝐨𝐩𝐨𝐥𝐲𝐦𝐞𝐫 𝐑𝐞𝐬𝐢𝐧 on the 𝐏𝐫𝐨𝐅𝐥𝐮𝐢𝐝𝐢𝐜𝐬 𝟐𝟖𝟓𝐃. In about 4 hours, we had 4 mixers printed, and all of them came off the printer in clean, workable condition.

The fun part was testing: we flowed blue and yellow dyes into the channel and watched under the microscope as they gently mixed and gradually turned into a uniform green. Simple, but very satisfying to see the mixer doing its job in real time.

"𝐖𝐞 𝐮𝐧𝐝𝐞𝐫𝐬𝐭𝐚𝐧𝐝 𝟑𝐃 𝐩𝐫𝐢𝐧𝐭𝐢𝐧𝐠 𝐜𝐚𝐧 𝐬𝐨𝐮𝐧𝐝 𝐜𝐨𝐦𝐩𝐥𝐢𝐜𝐚𝐭𝐞𝐝, 𝐛𝐮𝐭 𝐰𝐢𝐭𝐡 𝐨𝐮𝐫 𝐂𝐨𝐦𝐩𝐥𝐞𝐭𝐞 𝟑𝐃 𝐏𝐫𝐢𝐧𝐭𝐢𝐧𝐠 𝐒𝐲𝐬𝐭𝐞𝐦, 𝐝𝐞𝐯𝐢𝐜𝐞𝐬 𝐥𝐢𝐤𝐞 𝐭𝐡𝐢𝐬 𝐜𝐚𝐧 𝐛𝐞 𝐝𝐞𝐬𝐢𝐠𝐧𝐞𝐝, 𝐩𝐫𝐢𝐧𝐭𝐞𝐝, 𝐚𝐧𝐝 𝐭𝐞𝐬𝐭𝐞𝐝 𝐚𝐭 𝐲𝐨𝐮𝐫 𝐛𝐞𝐧𝐜𝐡𝐬𝐢𝐝𝐞 𝐰𝐢𝐭𝐡𝐢𝐧 𝐚 𝐝𝐚𝐲."

If you are working in microfluidics and curious about embedded mixers or other applications, our team would be happy to share what we have learned and hear what you are working on, too.

A Complete 3D Printing System : https://cadworks3d.com/start-a-one-on...

---

*CAD File: License CC BY — JunckerLab is licensed under the Creative Commons Attribution license.
