Скачать или смотреть Honda CRV 2012-2016 4th gen Radiator Replacement (steps in description)

Give yourself at least 5-6 hours if you never did this before. Items needed:

Radiator (move old parts to the new radiator like rubber feet, temp sensor, etc)
10 and 12mm tools
Screwdrivers
Paper towels
Needle nose pliers
Antiseize compound
Coolant 2 gallons
Hose clamp if corroded
Ramps
Flashlight
Clip remover tool
Large radiator funnel for burping
5 gallon pail

Steps:

1) Move car to ramp or lift front
2) Remove splash guard
3) Relocate hood stand
4) Drain coolant (loosen cap)
5) Remove upper, lower, recovery hoses
6) Remove grille (see Zach Fields vid    • CR-V Grill Removal and Replacement   )
7) Remove hold down brackets
8) Remove horn bracket
9) Unplug fans and temp sensor
10) Unclip hood latch cable but dont remove latch
11) Remove bulkhead
12) Remove fans
13) Remove radiator

Install in reverse order and add coolant and burp with heater on

Torque
fans 7nm
Bulkhead 10nm
Hold down brackets 12nm
Temp sensor 10nm
