Скачать или смотреть Strix Binary F10 Test and Tune 3/28/19 Butterflight 3.6.6

Floss 3.0
TMotor F-40 Pro v2 2400kv
Foxeer Predator Micro / Runcam microeagle
Crossfire Nano
Tramp HV
Lumenier AXII LHCP
DALRC Rocket 50A 4-in-1 BLHeli32
HQProp DP 5x4.3x3 PC V1S
Strix Binary F10
Buzzer from bangood
Microphone from bangood
battery 4s 100c 1300mah

DIFF
ButterFlight / STRIXF10 (SX10) 3.6.6 Feb 17 2019 / 23:37:21 (fd2da9086) MSP API: 1.40
IMU-F Version: 1109

board_name
manufacturer_id

name
name WIN 5S

resources

mixer

servo

servo mix


feature
feature -AIRMODE

map
map TAER1234

serial
serial 0 4 115200 57600 0 115200
serial 4 8192 115200 57600 0 115200

led

color

mode_color

aux
aux 0 0 0 1700 2100 0 0
aux 1 1 1 900 1125 0 0
aux 2 2 1 1300 1700 0 0
aux 3 13 2 1300 1700 0 0
aux 4 28 1 1300 2100 0 0
aux 5 31 3 1900 2100 0 0
aux 6 35 2 1700 2100 0 0
aux 7 39 3 1300 1700 0 0

adjrange

rxrange

vtx

rxfail

master
set align_gyro = CW0
set gyro_sync_denom = 1
set imuf_mode = 32
set imuf_rate = 32K
set align_acc = CW0
set acc_calibration = 3,-104,-48
set min_check = 1010
set max_check = 1990
set rssi_channel = 16
set fpv_mix_degrees = 35
set serialrx_inverted = ON
set blackbox_p_ratio = 64
set min_throttle = 1010
set dshot_idle_value = 409
set use_unsynced_pwm = OFF
set motor_pwm_protocol = DSHOT1200
set motor_pwm_rate = 32000
set failsafe_switch_mode = KILL
set vbat_scale = 110
set ibata_scale = 1205
set yaw_motors_reversed = ON
set small_angle = 35
set osd_units = IMPERIAL
set osd_vbat_pos = 2081
set osd_rssi_pos = 2093
set osd_tim_2_pos = 2103
set osd_flymode_pos = 2414
set osd_crosshairs_pos = 2286
set osd_current_pos = 2086
set osd_mah_drawn_pos = 2097
set osd_craft_name_pos = 2381
set osd_warnings_pos = 2346
set debug_mode = GYRO_SCALED
set vtx_band = 5
set vtx_channel = 7
set vtx_power = 4
set vtx_freq = 5880
set vcd_video_system = NTSC

profile
profile 0

set dterm_lowpass_hz = 115
set vbat_pid_gain = ON
set feedforward_transition = 5
set p_pitch = 39
set i_pitch = 54
set d_pitch = 23
set f_pitch = 5
set p_roll = 39
set i_roll = 52
set d_roll = 21
set f_roll = 5
set p_yaw = 64
set i_yaw = 52
set d_yaw = 9

rateprofile
rateprofile 0

set roll_srate = 71
set pitch_srate = 71
set yaw_srate = 69
set tpa_breakpoint = 1950
set tpa_type = BETAFLIGHT
