sUpPi UPS quick-start configuration

At a minimum, you will need to verify that your preferred Raspberry Pi operating system comes equipped with two device tree overlays-

dtoverlay=gpio-poweroff
dtoverlay=gpio-shutdown

and verify that you have both GPIO-16 and GPIO-17 free for sUpPi to use. (physical pins 36 and 11)

The relevant entries into '/boot/config.txt'

dtoverlay=gpio-poweroff,gpiopin=16,active_low=0
dtoverlay=gpio-shutdown,gpio_pin=17,active_low=0


Take note that upon first boot, using this method, that it will take some moments for the newly installed OS to expand and fill the micro-SD card. It is recommended to allow this process to complete before normal system usage.

Enjoy!
