Скачать или смотреть MFCL3780CDW wireless setup - Windows

Learn how to set up your MFCL3720CDW, MFCL3765CDW, MFCL3780CDW, or MFCL8395CDW color laser printer.

Models covered:
Brother MFCL3720CDW
Brother MFCL3780CDW
Brother MFCL3765CDW
Brother MFCL8395CDW

This video is for Windows users, for the Mac version click:
   • MFCL3780CDW wireless setup - Mac

For more videos, tutorials, and FAQs visit our support site at: http://www.brother-usa.com/support

Quick Links / Table of Contents:
Intro 00:00
Models covered - 00:10
Network name and password – 00:20
Set up the printer – 01:00
Download the software - 02:10
Running the Installer software - 00:30
Setup iPrint&Scan - 03:15

Transcript:
Welcome. Today we’re going to learn how to install your Brother MFC-L3780CDW on a wireless computer.

This video will cover multiple models and operating systems even though your machine may not match the model on the screen the overall process will be the same. (Covers MFC-L3765CDW and MFC- L3720CDW wi-fi setup too.)

You will need to gather some information about your wireless network in order to connect your machine. You will need to know the SSID or Network Name of your router or access point and you will need to know your Network Key or password.

The default settings for your router or access point can be found on the equipment label. If your SSID or Network Key contain both uppercase and lowercase letters be sure to record them as both of these credentials are case sensitive. You will also need administrator rights.

If you have setup up a custom SSID and Network Password and cannot recall this information, please contact your router manufacturer. Setup cannot be accomplished without this information.

Begin by pressing the wireless icon on the touchscreen

Select Find WI-FI Network

When prompted to switch network interface to wireless, press Yes.

Select you SSID or Network name and press OK

Enter your Network key using the touchscreen. Confirm that your Network Key is correct and press OK.

Once the wireless connection is made press OK

Go to setup.brother.com and download the installation software .

--Click here for more information on downloading drivers:    • How to download software, drivers, or util...

Navigate to your installer file and double-click to begin installation.

When the device installation window opens choose your language and click "Next."

Review the license agreement and click accept to continue. Then click "Next."

Enter your model number and then click "Next."

Select Wireless Network and then click "Next."
Click "Next"

Verify that your Brother machine is listed and click "Next"

Select Standard installation and click "Next."

When the software installation is complete click next. Now click “Close”

If your model supports scanning you will be prompted to install Brother iPrint&Scan.

To install, review the license agreement and click agree to continue. Then click "OK."

Click Select your Machine,

Verify the connection is set to Network. Select your model, then click OK

Click OK again

All the functions your machine supports will be displayed in the iPrint&Scan window. You are now ready to scan and print

For more Tutorials, FAQ's and Videos, visit us at brother-usa.com/support

Thank you for choosing Brother
