Screw DIATEST #pluggauge (BMD) for #boremeasurement into a #DIATRON1000

How to mount a #boregauge (BMD) from #DIATEST into a #DIATRON1000?

#Pluggauge (BMD):
Easy-to-use, self-indicating and self-centering bore gauge for the measurement of inner- and outer diameter, with highest precision and absolute accurate results. Field of application is the production of high-precision bores within a standard range of Ø 2.0 mm up to 270 mm in serial production.

Plug Gauge BMD allows:
Static and dynamic measurement
Detection of dimensional deviations and shape defects
As a hand tool in bores directly at the machine
Fitting in measuring fixtures and machines, e. g. automatic measurement in CNC machines

#DIATRON1000:
Complete system for #boremeasurement
with 4 decimal places: 0,0001 mm / 0,000005 Inch
Static and dynamic measurement
Integration into #DIAWIRELESS real radio network (optional) / Process integration
High resolution
High precision: ± 0.0002 mm linearity deviation over 3 mm travel
Additional linearization possible
