Machine description:
The filler Is a high-tech filling equipment integrating on the PLC microcomputer programmable control, and photo electricity transduction pneumatic action. The machine is especially designed for foodstuff and beverage. For example: white spirit, soy sauce, vinegar, seasoning, vegetable oil, syrup, mineral water, edible liquid as well as chemical liquid. It has accurate filling measurement; there is not bubble and drop. It suits for the filling of all kinds of bottle (including irregular bottle) ranging from 100 to 1000 ml.
Main features
1.0 High filling accuracy:
A,The filling cylinder is Driven by Servomotor,works reliable,more stable and accurate than normal piston driven machine.
B,Error compensation function available to add/reduce ml liquid for each filling head separately.(all adjustment are completed on
touch screen, no mechanical adjustment )
C, anti-dripping and anti-foam filling. Additional dripping collection available.
2.0 High automation & Easy operation
A,PLC touch screen and English working language for easier operation.
B, all controls accessible on touch screen.
C, low/high level warming, automatic refill and overflow recycling .
3,High flexibility :
A, able to fill different product like water , and dense liquid like cream, paste as well. B, different numbers of filling head to
meet different production capacity requirement.
C, Fit for bottles in different sizes, need only 5-10 min to change one size to another.
4, High quality and safety level.
A, main cabinet separately placed far above behind the filling nozzles,no worries of electrical shock caused by falling bottles.
B, full 304 stainless steel to meet food cleanness standard.
Basic parameters of filling line:
Model
EB-B1
filling range
100-1000ml
compressed air supply
0.6-0.8mpa
capacity
15 -20 bottles / min
power
380v 50Hz 7KW
weight
2000 kg
dimension
8200x1600x1800mm
SHENZHEN PENGLAI INDUSTRIAL CORPORATION LIMITD for manufacturing COSMETIC&FOOD&Pharmaceutical MAKING & PACKAGING MACHINES is a famous packaging solution provider in China!
The professional channel created by PENGLAI experienced engineer team covering all the machinery from making machines via filling capping machines to packaging equipments,offers the helpful knowledge in food&cosmetic&pharmaceutical field like shampoo making machine,vacuum food packaging,cream mixing equipments,etc.
As a famous-und experienced technical team we often design and manufacture unique machines to meet demands from global customers.There are in more than 150countries customers using our machines.Check the link for finding out which machines bought by them: https://penglaichina.com/news/
After-sales service
production line running for more than 5months in factory:
Guarantee: for all the machine, it claims one year for guarantee.(Excluded from the warranty are problems due to accidents, misuse,misapplication, storage damage,
negligence, or modification to the Equipment or its components.
ALSO THE EASY BROKEN SPARE PART IS NOT INCLUDED IN THE GUARANTEE)
Installation: after the machine arrive your factory,if you need,our technician will go to your place to install
and test the machine and also training your worker to operating the machine (The time of train depend on you worker).
The expenses (air ticket ,food , hotel,the travelling fee on your country) should be on your account and you need paid for the technician USD50 per day. also you can go to our factory to do training.
After-sale service: If you get the problem on the machine ,our technician will go to your place to fixed the machine as soon as possible.The cost should be in your account.(as above).
