Full automatic Frozen dumplings packing machine with multiheads weigher dimple face plate

Technical characteristics:
1．English and Chinese screen display, the operation is simple.
2．PLC computer system, the function is more stable, adjustment any parameters not need stop machine.
3．It can stock ten dispose , simple to change variety.
4．Sever motor drawing film , position accurately.
5．Temperature independent control system, precision get to±1℃.
6．Horizontal , vertical temperature control, suitable for various of mix film , PE film packing material.
7．Packing type diversification, pillow sealing, standing type, punching etc.
8．Bag–making, sealing, packing, print date in one operation.
9．Work circumstance quiet, low noise.

技术参数（Technical parameters）:
机型（Type） TCLB-420AZ
制袋长度(Bag length) 80-300mm(L)
制袋宽度(Bag width) 50-200mm(W)
薄膜宽度(Max width of roll film) 420mm
包装速度(Packing speed) 5-60bags/min
计量范围(Measuring range) 150-1200ml
气压(Air consumption) 0.65mpa
耗气量(Gas consumption) 0.3m³/min
电压（Power voltage） 220V
功率（Power ） 2.2KW
外型尺寸（Dimension） (L)1320mm×(W)950mm×(H)1360mm
机器重量（Deadwight of machine） 540Kg
