This live session will focus on Ethernet troubleshooting with a deeper dive into how Ethernet CIP Motion applications are affected by marginal or poorly engineered Ethernet implementations.

The discussion will include:
• Ethernet Media counters and what they mean
• SmartPorts and when to use them
• Duplex is not just housing
• How to find an IP address on a device
• Master Clock Issues with CIP Motion

Join us live on July 1, 2020!

Timecodes:
0:00 - Go live
2:52 - Typical Network Issues
8:41 - IPConfig /all command
10:12 - Ping command
11:39 - Finding an IP address with Wireshark
18:10 - Ethernet Media Counters
18:19 - Alignment Errors
19:00 - FCS Errors
19:13 - Collisions
20:36 - SQE Test Errors
21:01 - Mac Trasmit Errors
21:18 - Carrier Sense Errors
21:44 - Mac Receive Errors
22:00 - Duplex Mismatch issues and demo
29:31 - Stratix Smartports
32:41 - DLR How to find the Supervisor by LEDs
37:01 - CIP Sync IEEE 1588 PTP Definition
40:13 - Drive Properties - Motion Diagnostics
40:38 - Enable Transmission Timing Statistics
41:01 - Causes of Jitter / Sync Issues
43:44 - Clock Issues Demo - Grandmaster and Master Clock issues
54:23 - CIP Sync Troubleshooting Flow Chart
55:13 - Servo Startup issues
