In this video, Jochem explains why many people choose the MW series pressure gauges from WIKA. And what to look out for when selecting the right pressure gauge for your application. View our range here ► https://tameson.com/measurement-contr...
-------------------------------------
Timecodes:
00:00​ - Intro
00:13 - Bottom or back entry connection
00:19 - Pressure gauge applications
00:30 - Pressure gauge case diameter
00:34 - Determining the accuracy class of a pressure gauge
00:55 - Measuring range and scale options
01:03 - Connection thread size
01:14 - Choosing a pressure gauge
01:28 - Oil-filled gauges for pulsating pressures or vibrations.
01:38 - Why the MW pressure gauge
01:53 - Outro
-------------------------------------
Tameson is your online specialist for fluid control. On our website, you will find very clear information and tools to directly order the right product for your application. We have over 100,000 products in stock with new product types and variants added on a continual basis. Solenoid valves, ball valves, pneumatic cylinders, hoses, fittings, etc. you name it we have it or can get it. Our engineering support team and global delivery options allow for new and existing customers (B2B & B2C) to get the right product(s) at the right cost.

VISIT OUR WEBSITE:
USA, Canada & rest of world ► https://tameson.com/?utm_source=youtu...
United Kingdom ► https://tameson.co.uk/?utm_source=you...
Netherlands & Belgium ► https://tameson.nl/?utm_source=youtub...

FOLLOW US ON SOCIAL MEDIA:
Twitter ►   / supporttameson
Facebook ►   / tamesonfluid.  .
LinkedIn ►   / tame.  .

TAMESON NEWSLETTER SUBSCRIPTION
It is straight forward, no nonsense, and full of relevant information about the fluid control industry once a month. We have new product announcements, technical articles, special pricing, and much more that you'll have to subscribe to see!
English ► https://tameson.us16.list-manage.com/...
Dutch ► https://tameson.us16.list-manage.com/...

-------------------------------------------
The pressure gauges of the MW series are available with a bottom or back entry connection. The pressure gauge uses a tubular spring principle, also known as the bourdon principle. They are suitable for clean and non-viscous liquids and gases such as compressed air or water.

The case diameter is 40, 50 or 63 mm. The accuracy class for the steel case is 1.6 percent and for the plastic case 2.5 percent. This means that if you have a pressure gauge with a steel case and a maximum pressure of 10 bar, the pressure gauge will have a deviation of plus or minus 0.16 bar.

This number indicates the maximum positive or negative deviation. The measuring range for the pressure gauges of this series ranges from -1 to 400 bar and the scale varies from 0.02 to 50 bar.
The connection has a thread size of 1/8th or quarter inch and is made of brass. Therefore, ensure that your medium is compatible with brass.

As a rule of thumb, choose a pressure gauge where the operating pressure does not exceed 75% of the maximum scale value. For pulsating pressures, an operating pressure around 65% of the maximum scale value is advised. Do you have pulsating pressures or vibrations? Take a look at our oil-filled gauges. The oil in these pressure gauges dampens the vibrations, indicating an average constant value.

Three reasons why the MW pressure gauge is the perfect product for you:
It is reliable and cost-efficient
It is designed according to the EN 837-1 standard
It is available in vacuum versions
-------------------------------------------
