🚀 *Common Source Amplifier Layout Design*

Today we are building a Common Source Amplifier Layout from scratch in Cadence Virtuoso.

😲⚡️ If you want to speed up your design process like I do in this video, *don't forget to grab my Virtuoso Hotkey Cheat Sheet and Design Flow manual below!*

🚀 *Grab the Master Bundle* : https://rzp.io/rzp/4cUKw6q

💥 *The CMOS Inverter Design & Verification Manual*: A deep dive into the full Cadence workflow. It covers everything from Environment Setup to Parasitic Extraction.

💥 *The Ultimate Shortcut Cheat Sheet*: Every key you need for Schematic, Layout, and Waveforms on one page!

📌 What You’ll Learn Today:

💥 Analog Routing: Handling the bias and load connections without creating massive parasitic resistance.

💥 The "Integrated Body" Trick: Why setting the body to "Integrated" is a lifesaver for amplifiers.

💥 Post-Layout Simulation: Using QRC Extraction to see the real-world performance of your amplifier.

🚀 *Join the Tribe!*
💥 Become a channel member for exclusive perks, including:

💥 Member-Only Doubt Solving: Post your error screenshots in our community tab!

⏰ *Timestamps* :
00:06 – Let's Begin!
00:55 – Launch Layout XL
01:28 – Connectivity: Generate All from Sources
02:27 – Shift + F
02:50 – Check your Schematic quickly!
03:34 – Connectivity: Show/Hide All Incomplete Nets
04:06 – Note what happens when you Rotate your MOSFETs!
06:27 – Announcement for You!!!
10:02 – Check Description 👇🏻
11:07 – Let's Continue!
12:44 – Body Terminal - Focus!
14:00 – How to Flip the MOSFET!!!
16:02 – Connect the Output Terminal
16:34 – Connect the GND
16:44 – Connect the VDD
16:50 – Connect Vbias
17:05 – Error Avoidance
17:30 – Connect Vin
18:23 – Time for ASSURA
18:42 – Run DRC
19:34 – Run LVS
20:29 – Run QRC
21:50 – av_extracted view
22:11 – Shift + F & view the Parasitics!
25:00 – Next Lab: Differential Amplifier
💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥💥
