Item: Vertical Lathes (carousel)
Catalogue No.: 10837
WWW: https://strojesvoboda.cz/e10837
Model, parameters: SK 16 CNC
Producer: TOS
Production/refurbished:
???/2008
Description:
max. diameter of turning left smykadlovým slide 1700 mm
max. distance between the clamping plate and knife holder slide left ram 1250 mm
max. ram extension Left slide in 660 mm
Max. protrusion of the turret slide 550 mm Z
Revolving slide cross travel X 1020 mm
cross travel slide left ram U 980 mm
Clamping plate diameter 1620 mm
max. workpiece weight of about 5000 kg
max. section of the body knife 40x40 mm
Power of main engine control and 30 kW / A 52.3
nominal speed main engine 1475 rev / min.
servomotors lateral displacement X, U 22 Nm -3000 rev / min.
Servomotors strips Z, V 22 Nm -3000 rpm / min.
SERVOSTAR 614 servo inverters
hydroaggregate motor power of 2.2 kW (1450 rev / min.)
SINUMERIK 840 Di
Number of NC axes 5
position measuring axes X, U, Z, V
Transducer rotating table
hydraulic power unit:
Nominal tank capacity of 30 dm3
Supplied quantity 10 dm3 / min
infinitely variable speed in 4 rows for running left and right:
Series I. 1-12,5 rev / min.
II. range 5 to 27 rev / min.
III. range from 10 to 60 rev / min.
IV. range from 15 to 122 rev / min.
rychlopusuv:
Programmed in all slides 5000 mm / min.
In manual mode 4500 mm / min.
Machine floor space (WxD) 4550x2670 mm
machine height above ground 4630 mm
weight machines, including electric. cabinets and units of about 18500 kg max. diameter of turning left smykadlovým slide 1700 mm
max. distance between the clamping plate and knife holder slide left ram 1250 mm
max. ram extension Left slide in 660 mm
Max. protrusion of the turret slide 550 mm Z
Revolving slide cross travel X 1020 mm
cross travel slide left ram U 980 mm
Clamping plate diameter 1620 mm
max. workpiece weight of about 5000 kg
max. section of the body knife 40x40 mm
Power of main engine control and 30 kW / A 52.3
nominal speed main engine 1475 rev / min.
servomotors lateral displacement X, U 22 Nm -3000 rev / min.
Servomotors strips Z, V 22 Nm -3000 rpm / min.
SERVOSTAR 614 servo inverters
hydroaggregate motor power of 2.2 kW (1450 rev / min.)
SINUMERIK 840 Di
Number of NC axes 5
position measuring axes X, U, Z, V
Transducer rotating table
hydraulic power unit:
Nominal tank capacity of 30 dm3
Supplied quantity 10 dm3 / min
infinitely variable speed in 4 rows for running left and right:
Series I. 1-12,5 rev / min.
II. range 5 to 27 rev / min.
III. range from 10 to 60 rev / min.
IV. range from 15 to 122 rev / min.
rychlopusuv:
Programmed in all slides 5000 mm / min.
In manual mode 4500 mm / min.
Machine floor space (WxD) 4550x2670 mm
machine height above ground 4630 mm
weight machines, including electric. cabinets and units of about 18500 kg
