Скачать или смотреть Configure Zebra ATR7000 in ClearStream 8.1: RTLS & Portal Mode Demo

Learn how to unlock the full power of Zebra’s ATR7000 phased-array UHF reader using ClearStream RFID 8.1 and the PTS Cloud portal. We cover BOTH ATR7000 modes supported in ClearStream 8.1:

RTLS (XY coordinates): Use the ATR7000’s 97 “flashlight” beams to estimate tag positions and visualize them on floor-plan maps in the PTS Cloud. Drag-and-drop readers, define coverage, upload reference data (assets/employees), and trigger event flows (emails/SMS) when items move between areas.

Portal / Directionality mode: Configure 4-zone or 6-zone lanes over a choke point (e.g., a dock door) to detect in/out movement. Tune lane width, orientation, reader height, polarization, and reporting behavior—then stream events to PTS Cloud or your own DB (SQL Server, Oracle, MySQL, PostgreSQL, Access, Excel, REST/RIA).

What you’ll learn

ATR7000 overview (PoE, integrated antennas, phased-array beams, typical accuracy)

Setting up ClearStream 8.1 for RTLS and pushing live locations to PTS - RTLS Maps

Building rules and notifications when items move between zones

Enabling Directionality mode via Zebra IoT Connector, including lane plans (4/6), orientation, hysteresis, and update cadence

Mapping fields (EPC/TID/User Bank, antenna, direction, zone from→to) to your destination

Parsing GS1 EPC fields and joining tag reads to your asset master data

Practical notes on accuracy, latency vs. precision, and reflective environments

Who it’s for
Operations leaders, IT/OT teams, integrators, and warehouse/logistics managers who want fast, configurable location and portal movement tracking without a heavy engineering lift.

Free trial:
Go to http://www.clearstreamrfid.com for your free trial.
