Скачать или смотреть ASUS Board Wouldn't Start and Almost Burned | Repair of ASUS ROG Strix B450-F Gaming

Today on the bench, I have an ASUS ROG STRIX B450-F GAMING motherboard that arrived with a no-POST issue caused by a short circuit.

🔧 Topics covered:
Motherboard no-POST diagnosis
Short circuit detection on PC motherboards
DDR memory power rail faults
Shorted capacitor repair
Bench power supply current limiting
Thermal camera troubleshooting
ASUS AM4 motherboard repair

💬 Got a similar motherboard issue? Leave a comment — I read every one and may feature your case in a future video!

👍 Like, Share & Subscribe for more electronics repair content.
