NIVOSWITCH RCM – Mini compact vibrating fork level switch for liquids

The NIVOSWITCH RCM level switches with parallel vibrating fork are suitable for level detection of liquids. Mounted on pipes, or tanks it can control filling/emptying also can generate fail-safe alarms providing overfill- or dry run protection.
The operation principle is based on that the electronic circuit excites a vibration in the fork probe. When the medium reaches and covers the fork, its vibration changes or stops. The fork will start vibrating again as the medium sets it free. The electronics senses the change of vibration and gives an output signal after a selected delay.

MAIN FEATURES
■ Compact and mini compact type
■ Rod extension up to 3 meters
■ Plastic PFA coated version
■ Polished vibrating part
■ Hygienic versions with various process connections and 0.5-micron fine polishing
■ Selectable sensitivity
■ Relay or electronic output
■ Switching performance does not depend on the change of liquid conductivity, dielectric constant, pressure, and temperature
■ Medium temperature max. 130 °C
■ Output test with an optional test magnet
■ Ex version by ATEX and FM
■ IP67, IP65/IP68 protection

APPLICATIONS
■ Level switch of liquids: min. 0.7 kg per cubic decimeter density and max. 10^4 square millimeters per second viscosity
■ Food & beverages industry, animal feed, chemical industry, oil industry
■ For normal or hazardous, aggressive (acids, solvents) liquids
■ Covers a large variety of level detection, applications such as high/low fail-safe limit switch, overfill or dry run protection, pump controls

Model: NIVOSWITCH RCM-400-3
