Processor: Motorola 68EC030 or 68040 at 25 MHz
Bus speed: 25 MHz
RAM: 2-18 MB on board (2 MB "chip" RAM and up to 16 MB additional RAM);
Upgradable by further 128 MB via the CPU slot and 512 MB per Zorro III slot
ROM: 512 kB Kickstart ROM
Chipset: Advanced Graphics Architecture (AGA)
Video: 24-bit color palette (16.8 Million colors)
Up to 256 on-screen colors in indexed mode
262,144 on-screen colors in HAM-8 mode
Resolutions from:
320×200 to 1280×400i (NTSC)
320×256 to 1280×512i (PAL)
640×480 (VGA), 800×600i, 1024×768i[4]
Horizontal scan rates of 15.60-31.44 kHz
Vertical scan rates of 50--72 Hz
Audio: 4 × 8-bit PCM channels (2 stereo channels)
28--56 kHz maximum DMA sampling rate (dependent on video mode in use)
Internal storage: 120 MB 3.5" IDE hard disk drive (upgradable)
Removable storage: 3.5" HD floppy disk drive (1.76 MB capacity)
Input/output ports: Analog RGB video out (DB-23M)
Audio out (2 × RCA)
Keyboard (6 pin mini-DIN)
2 × Mouse/Gamepad ports (DE9)
RS-232 serial port (DB-25M)
Centronics style parallel port (DB-25F)
Floppy disk drive port (DB-23F)
Internal buffered ATA controller (40-pin)
Expansion slots: 4 × 100pin 32-bit Zorro III slots
1 × AGA video slot (inline with Zorro slot)
3 × 16-bit ISA slots (requires bridgeboard to activate)
1 × 200-pin CPU expansion slot
4 or 5 × 72-pin SIMM slots
Operating system: AmigaOS 3.0 (Kickstart 3.0/Workbench 3.0)
Physical dimensions: W × H × D: 15 × 5 × 15¼" (380 × 125 × 395 mm)
Other: 2 × front accessible 3.5" drive bays
1 × front accessible 5.25" drive bay
2 × internal 3.5" drive mountings
Key lock (disables mouse and keyboard)
