MAX II MICRO KIT used as ALTERA USB BLASTER

A complete digital design lab at your fingertips! Equipped with an Altera MAX® II EPM2210F324C3 device and on-board USB Blaster circuit, the MAX II Micro Kit provides users the best and largest CPLD design resource. MAX II Micro board can also be used as a USB Blaster cable (JTAG mode programming only) by leveraging its on-board USB Blaster circuit.

MAX II Micro Kit

 Altera MAX® II EPM2210F324 CPLD device

USB Blaster (on board) for programming;

4 pushbutton switches

2 Red user LEDs

2 Yellow user LEDs

2 Green user LEDs

2 Blue user LEDs

50-MHz oscillator for clock sources

Powered by a USB cable (Type-A-Male to Type-A-Female)

MAX II Micro can be used as a USB Blaster, and programming mode supported depends on the configuration device of Altera board connected to MAX II Micro (Only JTAG programming mode is supported to configure MAX II Micro).

Size：86.36*57.4 mm

We can operate the kit in three different modes.

Normal JTAG Mode:
Switch1 ON
Switch2 OFF

USB BLASTER MODE:
Switch1 ON
Switch2 ON

POWER DOWN MODE:
Switch1 OFF
Switch2 ON
