Скачать или смотреть PTC Creo Parametric: Sheet Metal Design Tutorial Overview – Start from Scratch |

This video is an easy, beginner-friendly guide to sheet metal design in PTC Creo Parametric. Learn the basics and start making your own sheet metal parts.
🔗Watch Complete PTC Creo Parametric Course Playlist Here:-    • Learn PTC Creo Parametric | Complete Free ...
👉Join this channel to get access to perks:
   / @engineeringwithpritam
🔔 Subscribe for more Creo tutorials: [   / @engineeringwithpritam  ]
🙏 Thank you for watching!
💬 Got questions? Drop them in the comments, and I will be happy to help!

📌 What you will learn in this video:
✅ Getting Started: Start a new sheet metal part in PTC Creo Parametric.
✅ Converting Solid Parts: Convert a solid part into a sheet metal component.
✅Planar vs. Extrude: Learn the difference between the "Planar" and "Extrude" commands.
✅ Creating Base Walls: Use the Planar tool to create the main wall.
✅ Secondary Walls (Flat Tool): Add extra walls or flanges with the "Flat" tool.
✅ Defining Thickness: Learn when and how to set the part's thickness.
✅ Customizing Flat Walls: Customize wall shapes and angles.
✅ Understanding Flanges: Use the "Flange" tool to finish part edges.
✅ Unbending and Bending Back: Unbend a part to calculate its length, then bend it back.
✅ Y Factor (Bend Allowance): Understand the Y factor for accurate length calculations.
✅ Bend Order: Set the correct sequence for bends.
✅ Creating Forms (Sketched Bumps): Add features like sketched bumps.
✅Creating Drawings and Developed Views: Make a drawing with a flat pattern view and a bend table.

📌Timestamps📌
0:00 – Introduction to Sheet Metal in Creo
0:15 – Starting a New Sheet Metal Part
0:48 – Converting Solid to Sheet Metal
1:29 – Difference Between Planar & Extrude
2:51 – Creating Base & Secondary Walls
5:06 – Defining Thickness & Customizing Bends
7:17 – Using Unbend & Bend Back Features
7:59 – Understanding Y-Factor for Bend Allowance
8:57 – Adding Form Tools (e.g., Sketched Bumps)
9:45 – Creating Drawing with Flat Pattern View
11:17 – Inserting Bend Table in the Drawing
12:05 – Final Summary & Outro
