Step-by-step plan - Connecting and programming control box

1. Place the coloured wires as shown in the video
2. Flip the red switch
3. Press and hold red PROGRAM button for 3 sec.
4. Press OPEN. The red light of the OPEN button will illuminate
5. Also check that the direction of rotation is correct. If not... the power supply to the motor must be reversed
6. When the desired OPEN position is reached, stop the motor with the same button
7. Switch the system OFF and ON. This stores the position
8. Then repeat these operations for the CLOSED position
9. Store both states by pressing the PROGRAM button 3 times
10. Test if both positions are programmed as desired
