Скачать или смотреть C.E. Howard 600 GAL 304 Stainless Steel Single Wall Mixing Tank Demonstration

To view additional machinery on our website click here: http://www.fraingroup.com/equipment-c...

C.E. Howard, 600 gallon, 304 stainless steel, single wall tank. Vessel dimensions: 78" diameter x 30" straight wall. Equipped with a side mounted 3/4 HP driven single motion dual prop mixer. Top prop has a diameter of 10" and bottom prop has a diameter of 14". Vessel has a dome top with (1) 54" x 26" semi-circle man way, (1) 19" ID manway with lift up cover, (1) 6"OD/2.5"ID 4 bolt flange, (1) 3/4" threaded port and (1) 9" x 4" slot for prop shaft. The sidewall has (1) 7.5"OD/3.5"ID 4 bolt flange. Slant bottom has (1) 3.5"OD/3"ID sanitary fitting with 8" ground clearance. Mounted on (4) stainless steel legs.

OAD: 86"L x 83"W x 78"H
