Скачать или смотреть Replacement TRANSFER Belt & Blade RICOH MP 8001 8000 7502 7500 7001 7000

If you have an ERROR SC440-01 SC440-02 check TRANSFER for: RICOH AFICIO 1050 1055 1060 1075 1085 1105 2051 2060 2075 2090 2105 550 551 650 700 850 MP5500 MP5500SP MP6000 MP6000SP MP6001 MP6001SP MP6002 MP6002SP MP6500 MP6500SP MP7000 MP7000SP MP7001 MP7001SP MP7500 MP7500SP MP7502 MP7502SP MP8000 MP8000SP MP8001 MP8001SP MP9001 MP9001SP MP9002 MP9002SP / GESTETNER 10502 10512 2640E 2850E 32105 3240 3255 3265 3270 3285 3355 3370 6002 7502 8502 9002 DSM651 DSM651SP DSM660 DSM660SP DSM675 DSM675SP DSM755 DSM765 DSM775 MP6000 MP6000SP MP6001 MP6001SP MP7000 MP7001 MP7001SP MP8000 MP8000SP MP8001 MP8001SP MP9001 MP9001SP / LANIER 5040CPS 5040MFD 5255 5255MFD 5265 5265MFD 5455 5470 5485 5505 5685 5705 LD0105 LD055 LD060 LD075 LD090 LD151 LD160 LD175 LD255 LD255SP LD260 LD260SP LD265 LD265SP LD270 LD270SP LD275 LD280 LD280SP LD360 LD360SP LD370 LD370SP LD380 LD380SP LD390 LD390SP LP275HDN MP6002 MP6002SP MP7502 MP7502SP MP9002 MP9002SP / NASHUATEC D3640 D4105 D440 D455 D465 D485 D4850 D5505 D555 D570 D8505 MP6000 MP6000SP MP7000 MP7000SP MP8000 MP8000SP / IBM Infoprint 2060ES 2075ES 2085 2090ES 2105 2105ES

Transfer belt unit
1. Disconnect the earth terminal and transfer current terminal. While doing this, hold the transfer belt unit by its knobs.
2. Raise and stand the belt perpendicular to the unit and remove it.
To avoid scratching the belt on the guide, never rotate the belt unit farther than 90 degrees
3. Release the drive roller
4. Press in on the drive roller to collapse the unit into a “U” shape
5. Remove the belt and replace it.
Re-installation
Before re-assembling the transfer belt unit, use a clean cloth and alcohol to clean the contact
points of the drive roller, idle roller, and transfer roller. Make sure these areas are clean and
free from toner, paper dust, etc.
Never touch the surface of the belt with bare hands and never apply alcohol to the surface of
the belt. Clean it with a blower brush. Check the underside of the transfer belt and clean with
the blower brush.
When re-assembling the transfer belt unit, make sure that the transfer belt is centered
between the triangular marks on either side of the unit.
After re-assembly, make sure that the transfer belt is inside the transfer current terminal. The
belt could be cut if it is not positioned correctly.
Confirm that both the ground and transfer current terminal are connected and that the
harnesses are not touching the release lever.
After re-installing the transfer belt unit, turn the belt and confirm that the toner collection coil
turns.
The transfer belt and transfer roller cleaning blade must always be replaced together
