RGM-84 Harpoon Blok II - Anti Ship Missile System is an all-weather, over-the-horizon anti-ship missile system, developed and manufactured by McDonnell Douglas (now Boeing Defense, Space & Security). In 2004, Boeing delivered the 7,000th Harpoon unit since the weapon's introduction in 1977. The missile system has also been further developed into a land-strike weapon, the Standoff Land Attack Missile (SLAM).

Harpoon Block II+ ER
In April 2015, Boeing unveiled a modified version of the RGM-84 it called the Harpoon Next Generation. It increases the ship-launched Harpoon missile's range from the Block II's 70 nmi (81 mi; 130 km) to 134 nmi (154 mi; 248 km), along with a new lighter 300 lb (140 kg) warhead and a more fuel-efficient engine with electronic fuel controls. Boeing offered the missile as the U.S. Navy's Littoral Combat Ship frigate upgrade over-the-horizon anti-ship missile as a cost-effective missile upgrade option; complete Next Gen Harpoons would cost approximately as much as a Block II at $1.2 million each, with upgrades for an existing missile costing half that. The version is also called the Harpoon Block II + ER. Boeing claims the Block II+ ER is superior to the Naval Strike Missile through its improved turbojet giving it greater range and active radar-homing seeker for all-weather operation, as well as a lighter but "more lethal" warhead. Test shots in 2017 had been confirmed. In May 2017, Boeing revealed it was no longer offering the upgraded Harpoon for the frigate OTH missile requirement, but would continue development of it.

General characteristics
Primary function: Air-, surface-, or submarine-launched anti-surface (anti-ship) missile
Contractor: The McDonnell Douglas Astronautic Company – East
Power plant: Teledyne CAE J402 turbojet, 660 lb (300 kg)-force (2.9 kN) thrust, and a solid-propellant booster for surface and submarine launches
Length:
Air-launched: 3.8 metres (12 ft)
Surface and submarine-launched: 4.6 metres (15 ft)
Weight:
Air-launched: 519 kilograms (1,144 lb)
Submarine or ship launched from box or canister launcher: 628 kilograms (1,385 lb)
Diameter: 340 millimetres (13 in)
Wing span: 914 millimetres (36.0 in)
Maximum altitude: 910 metres (2,990 ft) with booster fins and wings
Range: Over-the-horizon (approx 50 nautical miles)
AGM-84D (Block 1C): 220 km (120 nmi)
RGM/UGM-84D (Block 1C): 140 km (75 nmi)
AGM-84E (Block 1E): 93 km (50 nmi)
AGM-84F (Block 1D): 315 km (170 nmi)
RGM-84F (Block 1D): 278 km (150 nmi).
RGM/AGM-84L (Block 2): 278 km (150 nmi)
AGM-84H/K (Block 1G / Block 1J): 280 km (150 nmi)
Speed: High subsonic, around 850 km/h (460 knots, 240 m/s, or 530 mph)
Guidance: Sea-skimming cruise monitored by radar altimeter, active radar terminal homing
Warhead: 221 kilograms (487 lb), penetration high-explosive blast
Unit cost: US$1,527,416
Date deployed:
Ship-launched (RGM-84A): 1977
Air-launched (AGM-84A): 1979
Submarine-launched (UGM-84A): 1981
SLAM (AGM-84E): 1990
SLAM-ER (AGM-84H): 1998 (delivery); 2000 (initial operational capability (IOC))
SLAM-ER ATA (AGM-84K): 2002 (IOC)
